MezzLight 250kg Handloaded Goods Lift
| Max Working Load (MWL) | 250 kg |
|---|
Key Features
- Floor mounted, no pit required
- Self- supporting mesh-clad shaft
- Platform docks 950mm above finished floor level
- Constant pressure control buttons at both levels
- Standard travel height up to 4m
- Standard usable platform size 1000mm x 800mm
- Same side or through car loading
- 2 stops (ground plus one level)
- Both level gates fitted with electrical and mechanical interlocks
- Emergency stop button
- Anti-slip platform surface
Description
The MezzLight Handloaded mezzanine lifts are the most cost-effective arrangement, enabling users to move goods such as boxes and crates safely and efficiently to secondary storage areas within buildings. With the platform docking at 950mm above the finished floor height at both landings’ items are easily loaded on by hand.
The MezzLight Handloaded has a 250kg maximum working load and usable platform size 1000mm x 800mm. A surface-mounted design avoids costly and time-consuming structural changes to the building commonly associated with pit-fitted installations and instead the compact, free-standing design of all mezzanine floor lifts in the range maximises useable floor space in customer’s premises, perfect when space is at a premium.
With UK design and manufacturing in house, standard size goods lifts are available off the shelf or a wide range of optional extras can be applied including bespoke platform sizes, increased height, increased stops, outside Installation and a choice of different finishes.
We only use our own engineers to carry out our rapid installations taking just 2 working days to complete and training is available throughout the UK.
Planned Maintenance Programmes which include Statutory Thorough Examinations by our nationwide network of service engineers ensure lifts remain safe and operational throughout their life.
MezzLift’s are CE marked and built-in conformance with the Machinery Directive 2006/42/EC, Lifting Operations & Lifting Equipment Regulations 1998 and The Provision & Use of Work Equipment Regulations 1998.
Downloads
Product Specific
Mezzanine Goods Lifts
Add-Ons/Options
- Bespoke platform sizes
- Increased travel height (up to 9m)
- Up to 3 stops (ground plus two additional levels)
- Outside Installation
- Choice of finish colour
- 90⁰ loading or additional entrances
- Fully clad enclosure
![Mezzpro 500Kg Goodslift[1]](/media/osxpzzfn/mezzpro-500kg-goodslift-1.jpg?width=500&height=500&format=webp&quality=90&v=1dc4d8a35b8c780)
![Bova 5[1]](/media/ntice205/bova-5-1.jpg?width=500&height=500&format=webp&quality=90&v=1dc4d95229072b0)
Why Choose a 250kg Handloaded Mezzanine Goods Lift?
Use your floor space more efficiently
Safely transfer goods between levels with a hand-loaded lift, maximising storage and operational capacity without expanding your footprint.
Work faster, handle less
By reducing hazardous and time-consuming manual handling, our trolley lifts help speed up the movement of goods and improve operational efficiency.
Built to last
Penny Engineering goods lifts are backed by world-class British engineering. We're proud to offer rapid lead times and a UK-wide network of service engineers to deliver on-demand support.
250kg Handloaded Mezzanine Lift FAQs
All our mezzanine lifts have a standard lead time of 4-6 weeks from placing the order.
Our lifts operate up to 4m or 2 stops (ground plus 1 level) as standard.
If you need assistance with specifying your mezzanine lift, please contact our sales office on 01246 811 475 or fill out our contact form.
